LED technology - OLEDs (Organic light emitting diodes)

Organic light-emitting diodes - OLEDs - emit light when a current flows through them. Unlike conventional LEDs, OLEDs are made from layers of plastic and other organic (carbon-based) materials.

Examples are already in mass production for displays in MP3 players and phones.

Sheets of OLED material are proposed to replace light bulbs and fluorescent tubes for house and office lighting.

There are several reasons why OLEDs are causing so much excitement amongst makers of gadgets and lighting products:
The materials are deposited by industrial coating processes which are cheaper than the techniques required to make conventional LEDs.
They are inherently thin.
They can be made on flexible plastic substrates - which will almost certainly lead to full colour flexible displays less than 1mm thick.
All colours, and multi-colours, are possible
However, there are drawbacks:
OLEDs are not yet as efficient at making light as conventional LEDs, although they are getting closer and already beat ordinary light bulbs.
Certain materials in OLEDs are incredibly sensitive to moisture which leads to short life, particularly on plastic substrates. This is the main reasons holding back flexible OLED manufacture.
LED technology can be divided into two: 'small molecule' championed originally by Kodak, and Cambridge Display Technology's 'polymer' type sometimes called P-OLEDs.

Almost all displays in production are small molecule.

These materials have to be deposited in a vacuum, but this is of little inconvenience for small displays on glass substrates.

Polymer types can also be vacuum processed but, most importantly, can also be printed using standard printing techniques. This 'solution processing' is far cheaper than vacuum processing.

Like-for-like materials have tended to be less efficient at producing light when solution processed, but this may no longer be the case.

OLEDs are generally made of several layers. The following is a typical stack, although many variations are possible:
Electron donor
Electron transport
Hole transport
Hole donor.

Several of these can be moisture-sensitive, particularly the most effective cathode material: metallic calcium.

For all practical purposes, glass blocks all moisture, so displays made on a glass substrate and covered by a second glass sheet can have a long life, particularly if the edges are hermetically sealed.

Moisture passes fairly easily through plastics, leading to much reduced durability, but plastic substrates are essential for flexible displays.

This has lead to a quest for 'barrier layers' which can be coated on plastic to stop moisture getting through.

So far there is no effective barrier layer that is flexible and cheap enough for mass-production.

Quite good barrier layers exist, which are quite expensive because they are made with many layers of water-blocking metal oxides, separated by other layers that stop the oxide cracking.

The dream is to produce OLEDs, both full-colour displays and white lighting types, on flexible plastic.
Not necessarily because the products will be flexed in use, but because they will be far more robust than millimetre-thick glass sheets to handle, transport, and install.

Within the molecules that make OLEDs emit light, there are two different processes that can produce light: phosphorescence and fluorescence, also known as triples and singlet emission respectively.

The type of emission is directly dependent on the materials used in the OLED.

Phosphorescent processes produce more photons (light) for a given number of electrons (current), but are slower - more suited to lighting, less suited to displays.
Some researchers that argue fluorescence can be made to produce as many photons as phosphorescence.

OLED displays should not be confused with E Ink displays - E Ink displays only reflect light and emit no light of their own.

Death of a Commodity

Lighting is definitely one of the most interesting areas of the electronics industry at the moment. After hardly any major changes in the near century and a half since Swan/Edison/A N Other first commercialised the concept, the humble light bulb now seems doomed unless it can be made efficient enough to compete with other lighting technologies.

While there are efforts to make light bulbs more efficient, other technologies are trying hard to replace them. The most promising of these is LED technology which is now in a position to fill many of the roles that are traditionally filled by incandescent lighting.

Manufacturers such as Cree and Lumileds are battling to have the top performing power LED, with regular announcements claiming either the best performance, or that LEDs have proven themselves for another new application, dental lighting and street lighting being the latest according to Lumileds.
However, LEDs may not have everything their own way, other technologies may challenge their current superiority. The light bulb could make a resurgence using a new coating which reflects back the IR energy and allows the filament to burn hotter and more efficiently.

Another interesting technology on the horizon is OLED lighting. This type of lighting may take a few years to hit the mainstream market, but looks a good bet for domestic and commercial lighting. OLED has many advantages; a more natural colour than LEDs, it is attractive, very efficient and should be very cheap to produce when some problems are ironed out.

CFL lighting also deserves a mention, but it suffers many of the same drawbacks of incandescent lighting only to a lesser extent, and also contains mercury, which can make disposal after use complex.

I will take a look more thoroughly at these technologies in future blogs and hopefully have a chance to speak to some of the leading companies in the field for a first hand perspective.

Led-World Exclusive -Researchers Develop Super-Efficient LED Light

LED light bulbs are already more efficient than your average bulb, but researchers at the Renssalaer Polytechnic Institute have developed a new kind of LED that exhibits both improved energy efficiency and lighting performance. The researchers‘ polarization-matching LED shows an 18 percent increase in light output and a 22 percent increase in wall plug efficiency (the amount of electricity that the LED converts into light).

Renssalaer’s LED is more powerful thanks to a reduction in “efficiency droop”, which makes LEDs most efficient when receiving low-density electrical currents and least efficient when higher density electrical currents are received.

The research team figured out that the region of the LED where light is generated contains materials with mismatched polarization. By reducing the polarization mismatch, electron leakage can also be reduced, thus increasing energy efficiency. So Renssalaer’s researchers introduced a new design with better matched polarization. As expected, they saw a reduction in efficiency droop and electron leakage.

Since LED lights are not yet entirely mainstream, advances made now can easily be implemented in both current and future LED installations.

Sunday, January 11, 2009

OSRAM LED Engineering Kit for Lighting Designers

The LED Engineering Kit, which OSRAM Opto Semiconductors is now offering for sale on the LED Light for You (LLFY) platform, provides a means of gaining practical knowledge of LED lighting.
This kit is a powerful tool for anyone who wants to test LEDs, various accessories and applications. The Engineering Kit includes components from various LLFY partners. In addition to the OSRAM OSTAR high-power LED, there are various lenses and reflectors, a power supply, a thermal interface and a selection of heat sinks. A brochure is also included for technical assistance.

Lighting designers, luminaire manufacturers and architects are all heavily involved in creating lighting systems that contain the latest technology. They can use the Engineering Kit as a simple way of gaining an insight into this new LED technology and test different LED lighting solutions. Different reflectors, lenses and heat sinks can be combined to create numerous variations and provide an idea of what the new light sources can achieve and what their special features are.

The Engineering Kit contains the OSTAR LED, two reflectors from Fraen with medium and narrow beam angles and three lenses from Ledil - one with a wide angle, a spot lens and a cat's eye for side deflection. A thermal interface from Laird that provides optimum heat dissipation, two heat sinks (from Coolermaster and an aluminum plate) an OSRAM Optotronic power supply for the European/Asian or NAFTA market round off the kit. The kit demonstrates the numerous options offered by these tiny light sources and indicates the accessories needed.

"An LED alone is not a light fitting", said Sebastian Lyschick, Network Manager LLFY at OSRAM Opto Semiconductors. "Our kit provides a quick and simple means of understanding the new LED technology and its exciting possibilities. It can be used as the basis for developing projects and products with network partners." The Engineering Kit and brochure are available exclusively at www.ledlightforyou.com/led-kit.

Led-World Exclusive -Cree Installs LED Lights in Pentagon

LED manufacturer Cree has been awarded a contract from the U.S. Department of Defense to supply over 4,200 recessed LED lights for the Pentagon, the company announced Tuesday. Financial details were not disclosed.

Testing commissioned by the U.S. government determined that Cree's LR24 recessed LED lights would offer a 22 percent energy reduction compared with fluorescent lights, and save the Pentagon 140 tons of carbon dioxide emissions per year.

The government also commissioned a cost analysis that showed the lights would yield a payback of less than four years once things like energy savings, maintenance, and the expense of properly disposing mercury-laden fluorescent bulbs were taken into account, according to Cree.

The new lighting will be installed in Wedge 5 of the Pentagon, coinciding with the major Pentagon renovation already under way in that area.

The purchase also happens to follow the advice of the American Recovery and Reinvestment Plan recently proposed by President-elect Barack Obama in his January 3 address.

As part of his plan to reduce reliance on foreign oil and create more jobs, President-elect Obama has suggested that the government will "renovate public buildings to make them more energy efficient."

Analysts have predicted that LED lighting will replace incandescent bulbs, making LED lighting manufacturers a bright spot to watch for within the struggling tech industry.

LED lights in Supermarket Refrigeration Gets Cheaper!

Led-World found that LED lighting systems enable big energy savings in supermarket refrigeration and have been getting cheaper every year.

LED system prices dropped 9% in 2008 alone and DOE's Solid State Lighting Research and Development Program projects they will fall by 50% by 2012.

In preliminary analysis released in August 2008, DOE showed that, assuming a 50% decline in LED prices, the highest standards would make sense for all supermarket refrigeration systems and would save purchasers $5 billion in net savings over 30 years.

However, for the analysis underlying today's standard, DOE rejected its own LED price estimates, instead assuming that LED prices will stay at 2008 levels forever.
